Strongmaster Mobile Welding Fume Extraction Unit
The StrongMaster is a high-efficiency mobile welding fume extractor designed for industrial use. IFA-certified and built for durability, it removes harmful fumes from high-alloy steel, galvanized metal, and aluminum. With a baffle pre-filter, compressed air cleaning, and >99% separation efficiency, it delivers reliable performance in demanding workspaces.
The StrongMaster mobile welding fume extraction unit is a high-efficiency mobile cartridge filter system engineered to remove harmful welding fumes from high-alloy steels, galvanized materials, and aluminum. With IFA certification, it meets strict air quality standards, allowing purified air to be safely recirculated into the workspace.
Designed for industrial durability, this unit features a baffle plate pre-filter that captures larger particulates before the main filter cartridge efficiently removes fine dust. The manual compressed air cleaning system extends the lifespan of the filter, reducing maintenance costs.
Built for flexibility and mobility, the StrongMaster is ideal for workshops and industrial applications where high-performance fume extraction is required.
Key Benefits
- Mobile design for flexible placement in workspaces
- IFA-certified filtration system ensures compliance with safety standards
- Manual compressed air cleaning extends filter life
- High separation efficiency (>99%) for welding fume and dust removal
- Baffle plate pre-filter enhances filtration performance
- Designed for high-alloy steel, galvanized materials, and aluminum applications
Applications
- Welding and fabrication workshops
- Metalworking industries
- Industrial fume and dust extraction
- Automotive and aerospace manufacturing
- Heavy machinery production
- Portable workstations requiring mobile filtration
Technical Data
Technical Specs
| Property | Value |
|---|---|
Volumetric Flow of Fan | 1,860 m³/h |
Max. Pressure | 2,900 Pa |
Operating Point | 1,100 m³/h @ 1,900 Pa |
Engine Power | 1.1 kW |
Supply Voltage | 400 V |
Current Consumption | 2.5 A |
Pre-Filter | Baffle Plate |
Main Filter | Filter Cartridge |
Filter Class | Dust Class M |
Cartridges Number | 1 |
Filter Surface | 10 m² |
Separation Efficiency | >99% |
Sound Level | Approx. 72 dB(A) |
Weight | 363.76 lbs |
Dimensions (inches) | W: 26.18, D: 86.61, H: 53.74 |
